ACM1552U-Y3 USB NFC Reader Module with Detachable Antenna Board
ACM1552U-Y3 USB NFC Reader Module with Detachable Antenna Board was developed based on the 13.56 MHz contactless technology. It can access contactless card and devices following the ISO 14443, ISO 15693 and ISO 18092 standards. This smart card reader module is designed to easily integrate embedded systems.
ACM1552U-Y3 is a CCID & PC/SC compliant reader, this plug-and-play NFC reader makes use of high-speed communication for contactless cards at a maximum of 848 kbps, which makes it suitable for highly demanding applications. It also supports three NFC modes:
- Smart Card Reader/Writer
- Card Emulation
- Keyboard Emulation (Configured by this tool)
By integrating the three NFC modes, this NFC reader module provides versatility, cost-effectiveness, and flexibility, making it a powerful and valuable solution for smart card applications.
ACM1552U-Y3 has a detachable antenna and an optional USB cable, allowing it to be the perfect front-end interface module for NFC transaction applications, including vending machine payment systems, kiosks, gaming machines, and other integrated systems.
Why Choose the ACM1552U-Y3 NFC reader Module?
- USB 2.0 Full Speed Interface
- CCID Compliance
- Contactless Smart Card Reader:
- Read/Write speed up to 848 kbps
- Built-in antenna for contactless tag access, with card reading distance of up to 70 mm (depending on tag type)
- Supports ISO 14443 Type A and B cards, ISO 15693 Cards and ISO18092 NFC
- Supports MIFARE Classic®, MIFARE® Mini, MIFARE Ultralight® (T=CL), FeliCa and Topaz Card
- Built-in anti-collision feature
- Supports extended APDU (max. 64 kbytes)
- One ISO7816-compliant SAM slot (Class A) (Upon Request)
- NFC Support
- Smart Card Reader/Writer Mode
- Card Emulation Mode
- Keyboard Emulation Mode
- Application Programming Interface:
- Supports PC/SC
- Supports CT-API (through wrapper on top of PC/SC)
- Peripherals:
- User-controllable bi-color LED (Blue & Green)
- User-controllable buzzer (Monotone)
- One SAM slot (Upon Request)
- USB Firmware Upgradability
Product Features and Technical Specifications
Might Also Like: Explore More NFC Solutions
If you’re interested in enhancing your NFC capabilities further, you might also like NFC Tools, which provide extensive functionalities for managing NFC tags. Additionally, consider the Square Reader for Contactless Payments that complements the ACM1552U-Y3 for seamless transaction processing.
NFC Reader: The Heart of Smart Technology
The ACM1552U-Y3 NFC Reader Module excels in its function as a reliable NFC Reader, capable of reading a variety of tags and cards, including NFC tags, smart cards, and RFID cards. With a high-frequency operation at 13.56 MHz contactless technology, it ensures swift transactions in just moments. This makes it ideal for environments requiring rapid and efficient connectivity, such as retail or access control applications.
NFC Functionality: Bridging Convenience with Security
The NFC functionality of the ACM1552U-Y3 provides a seamless experience for end-users. Users simply need to bring their NFC-enabled smartphones or contactless cards close to the reader, allowing for instant scanning and interaction. This feature not only enhances user experience but also strengthens security protocols, as the technology inherently reduces the risk of unauthorized access.
Read and Write Capabilities
This reader allows you to NFC Reader and write NFC tags effortlessly, giving you greater control over your data management. With the ACM1552U-Y3, you can encode information onto NFC tags, making it suitable for various applications like custom business cards, ticketing systems, and product labeling.
USB Connectivity: A Plug-and-Play Experience
The ACM1552U-Y3 NFC Reader connects via USB, making it easy to integrate into existing systems. Its compatibility allows it to work seamlessly with a range of operating systems, including Linux and Windows, expanding its usability in diverse technological environments. Simply connect it to your device, and watch as it powers up without the need for complex setup procedures.
IP65 Waterproof Rating: Built to Last
The ACM1552U-Y3 comes equipped with an IP65 waterproof rating, ensuring its durability in various conditions. This robustness means that it can operate effectively in environments where spills and splashes are likely, making it ideal for outdoor usage or in bustling retail spaces.
Customer Reviews: A Trusted Choice
Users have expressed overwhelming satisfaction with the ACM1552U-Y3, noting its reliability and efficiency. Many customers appreciate its NFC Forum certified status, emphasizing its compliance with recognized industry standards. Ratings and reviews highlight its ease of use, effectiveness in diverse applications, and solid construction.
SDK: Developer-Friendly Features
The unit comes with an SDK, enabling developers to easily integrate the ACM1552U-Y3 into their applications. This makes it a favorite choice for tech enthusiasts looking to innovate with NFC solutions. Its compatibility with various programming platforms allows for the creation of custom applications that utilize the rich features of the reader.
Contactless Payment Solutions
With the rise of digital wallets and contactless payment systems like Google Pay, having a reliable NFC reader like the ACM1552U-Y3 is critical for any retail business aiming to adapt to modern consumer preferences. This reader supports a variety of contactless smart card technologies, ensuring quick and secure transactions for your customers.
Technical Specifications Table
| Physical Characteristics | |
|---|---|
| Dimensions (mm) | Main Board: 55.0 x 45.0 x 6.5 Antenna Board: 91.0 x 49.5 x 5.0 |
| Weight (g) | 27.7 |
| USB Interface | |
| Protocol | USB CCID |
| Connector Type | USB Type-A |
| Power Source | From USB port |
| Speed | USB Full Speed (12 Mbps) |
| Cable Length | 1m, Detachable (Optional) |
| Contactless Smart Card Interface | |
| Standard | ISO 18092 NFC, ISO 14443 Type A & B, ISO 15693, MIFARE®, FeliCa |
| Protocol | ISO 14443-4 Compliant Card, T=CL MIFARE® Classic Card, T=CL ISO 15693 ISO 18092 NFC Tags FeliCa |
| Built-in Peripherals | |
| LED | 1 bi-color: Blue and Green |
| Buzzer | Monotone |
| Other Features | |
| Other Features | Supported Card Types:ISO 14443 Type A & B Parts 1-4, ISO 15693, ISO 18092 NFC, MIFARE Classic®, MIFARE® Mini, MIFARE Ultralight® (T=CL), FeliCa and Topaz CardSmart Card Reader/Writer, Keyboard Emulation, Card EmulationOther NFC Features: |
| Firmware Upgrade | Supported |
| Certifications/Compliance | |
| Certifications/Compliance | Certifications:IEC/EN 62368, CE, UKCA, FCC, VCCI, RoHS, REACH, WEEE, Microsoft® WHQLUSB CCID, PC/SCCompliance: |
| Device Driver Operating System Support | |
| Device Driver Operating System Support | Windows®, Linux®, macOS, Android™ |
Useful Information: Enhancing Your Experience
Usage Instructions
To utilize the ACM1552U-Y3, follow these simple steps:
- Connect the Device: Plug the module into your device via USB.
- Install Drivers: Ensure the correct drivers are installed for your operating system.
- Start Reading: Place an NFC tag or card within reading distance to start interacting.
Environmental Impact
By using NFC technologies such as the ACM1552U-Y3, businesses can streamline processes and reduce waste associated with traditional card and ticketing systems. NFC enables digital transformations that not only enhance user experiences but also promote eco-friendly practices by minimizing plastic use.
FAQs
1. Can I use this NFC reader with my smartphone?
Yes, the ACM1552U-Y3 is compatible with NFC-enabled smartphones, including both Android and iOS devices.
2. Is the reader suitable for outdoor use?
Absolutely, the IP65 waterproof rating makes it well-suited for outdoor applications.
3. How can I integrate this into my software?
The SDK provided with the module simplifies the integration into various software applications, enabling developers to create bespoke NFC solutions.
Conclusion: A Smart Investment for the Future
Investing in the ACM1552U-Y3 NFC Reader Module means choosing quality, versatility, and reliability. This NFC Reader module not only meets the demands of current technology but also future-proofs your operations as the industry evolves. Enhance your company’s operational efficiency and embrace the benefits of NFC technology today!
For more information or to request a sample, please contact us! Your tech evolution awaits.
